Weatherproof Rf Lc Filter / Lc Bandpass Filter High Aseismatic Capability

Product Categories
Chengdu SinoScite Technology Co., Ltd.
Contact Now

Weatherproof Rf Lc Filter / Lc Bandpass Filter High Aseismatic Capability

Brand Name : Sinoscite

Model Number : SNSD

Certification : ISO 9001:2015

Place of Origin : Sichuan, China

MOQ : 1 Piece

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 2000 Piece per month

Delivery Time : Less than 4weeks

Packaging Details : Standard exporting carton , each product individually wrapped, high density foam protection professional packing.

3dB Bandwidth : 900

Insertion Loss : <1.5dB

Nominal Center Frequency : DC-2000MHz

Pass frequency : >900MHz

VSWR : 2 max

Transition frequency bandwidth : <100

Name : passive lc filter

Contact Now

Reject Passive Components Weatherproof N Female High Pass Cavity LC RF Filter





Quick Details

  1. Place of Origin:Sichuan, China

  2. Brand Name:sinoscite, Sinoscite

  3. Model Number:BPF4-6GS-0563

  4. Type:LC Filter

  5. Transfer Function:Band Pass

  6. Nominal Center Frequency:12.7-13.3GHz

  7. Insertion Loss:1dB, <0..8dB

  8. Input Impedance:50Ohm

  9. Stopband Attenuation:20dB

  10. Description:low pass filter rf filter

  11. Impedance:50Ohm

  12. Filter Type:Low Pass

  13. Mounting Type:Surface Mount

  14. Height (Max):200

  15. Number of Lines:2

  16. Impedance @ Frequency:50Ohm

  17. Voltage Rating - DC:220v

  18. Voltage Rating - AC:220V



Our Products Features:



1. Good temperature behavior, High aseismatic capability.

2. Low Insertion Loss, High power handling.

3. High quality, Low price, Fast delivery.

4. Custom design available upon request.

5. Meet ROHS standard.

6. Guaranteed for one year standard





Typial Applications



Single-phase power supplies,swich-mode power supplies.



Small to medium-sized machines household equipment.



Test and measurement equipment.



Medium equipment.



1~ 2000MHz High Pass LC RF Filter



Pass Frequency

(MHz)

3dBCut-off Frequency

(MHz)

 Transition Frequency Bandwidth(MHz) Out of band inhibition(dB)

Insertion Loss

(dB)

Intra Band Fluctuation

(dB)

 Internal reflection loss(dB)
>180 180 <20 >50 <1.5 <1.5 >10
>240 240 <26 >50 <1.5 <1.5 >10
>370 370 <240 >50 <1.5 <1.5 >10
>650 650 <70 >50 <1.5 <1.5 >10
>900 900 <100 >50 <1.5 <1.5 >10
>1500 1500 <160 >50 <1.5 <1.5 >10
>2000 2000 <220 >50 <1.5 <1.5 >10



Forms are specify frequency range and other ranges available



Tip: Attention should be paid to the good grounding of the enclosure when it is used, otherwise it will affect the external suppression and flatness index





Packaging & Shipping

Packing:Standard exporting carton.

each product individually wrapped, high density foam protection professional packing protect product safely.

Airport: Shanghai airport, Shenzhen airport and Chengdu Airport.
